Drilling Machine Manufacturer India for All Kinds of Drilling Machines

Drilling machine is a power machine used to cut holes into or through metal, wood, or other materials. Drilling machines use a drilling tool that has cutting edges at its point. Mostly drilling machines are made of steel or diamond. It rotates at a high speed. By the drill machines the bit is pressed against the work piece which rotates very fast approximately hundreds to thousands revolutions per minute. Drill Machine Head-A part of drill that is located at the top end that penetrates through the material. The drilling machines perform wide range of functions including drilling, wood working, reaming, metal working, grinding, construction, tee slot cutting and counter sinking etc.

The main components of drilling machine are:

Spindle: The spindle holds the drill or cutting tools and revolves in a fixed position in a sleeve.
Sleeve: The sleeve does not revolve but may slide in its bearing in a direction parallel to its axis.
Column: The column is cylindrical is shape and built rugged and solid. The column supports the head and the sleeve assembly.
Head: The head of the drilling machine is composed of the sleeve, a spindle, an electric motor and feed mechanism. The head is bolted to the column.

Products

Specification

Drill Machine EPD- 12

Drilling capacity in mild steel

12 mm

Pillar Diameter

46.5 mm

Spindle nose to table distance

330 mm

Distance from spindle center to Pillar surface

151 mm

Table Travel

215 mm

Taper in spindle

1/2" Drill

Number of speed

4 Speed

Spindle Travel

75 mm

Pillar Length

90 mm

Overall height with pulley guard

1420 mm

V-Belt section

A

Weight (Approx.)

40 kg.

Ram Diameter(MM)

0.5 HP

Drill Machine EPD- 15

Specification

Drill Machine EPD- 15

Drilling capacity in mild steel

15 mm

Pillar Diameter

58.5 mm

Spindle nose to table distance

482 mm

Distance from spindle center to Pillar surface

177 mm

Table Travel

305 mm

Taper in spindle

MT 2

Number of speed

4 Speed

Spindle Travel

100 mm

Pillar Length

840 mm

Overall height with pulley guard

1143 mm

V-Belt section

A

Weight (Approx.)

60 kg.

Ram Diameter(MM)

495 mm

Motor1440 RPM 3 Phase440 volts

0.5 HP

Drill Machine EPD- 19

Specification

Drill Machine EPD- 19

Drilling capacity in mild steel

19 mm

Pillar Diameter

74.5 mm

Spindle nose to table distance

430 mm

Distance from spindle center to Pillar surface

217 mm

Table Travel

381 mm

Taper in spindle

MT 2

Number of speed

8 Speed

Spindle Travel

140 mm

Pillar Length

990 mm

Overall height with pulley guard

1295 mm

V-Belt section

A

Weight (Approx.)

125 kg.

Ram Diameter(MM)

58 mm

Motor1440 RPM 3 Phase440 volts

1 HP

Drill Machine EPD- 25

Specification

Drill Machine EPD- 25

Drilling capacity in mild steel

25 mm

Pillar Diameter

90 mm

Spindle nose to table distance

710 mm

Distance from spindle center to Pillar surface

259 mm

Table Travel

485

Taper in spindle

MT 3

Number of speed

8 Speed

Spindle Travel

165 mm

Pillar Length

1450mm

Overall height with pulley guard

1840 mm

V-Belt section

B

Weight (Approx.)

180 kg.

Ram Diameter(MM)

64 mm

Motor1440 RPM 3 Phase440 volts

1 HP

Drill Machine EPD- 32

Specification

Drill Machine EPD- 32

Drilling capacity in mild steel

32 mm

Pillar Diameter

90 mm

Spindle nose to table distance

710 mm

Distance from spindle center to Pillar surface

259 mm

Table Travel

885

Taper in spindle

MT 4

Number of speed

8 Speed

Spindle Travel

165 mm

Pillar Length

1450mm

Overall height with pulley guard

1840 mm

V-Belt section

B

Weight (Approx.)

185 kg.

Ram Diameter(MM)

64 mm

Motor1440 RPM 3 Phase440 volts

1.5 HP
