Hydraulic Press Brake India Manufacturer Of World Class Machines At Responsible Cost
A Hydraulic Press Brake is a type of press brake that is powered by a hydraulic cylinder to cycle the ram. The hydraulics allows the press to be stopped at any time during its stroke. These press brakes are manufactured to high standards of life time durability and precision accuracy, safety and control. These press brakes are highly productive, versatile, accurate, rugged, economical, easy to operate and maintain. This facility ensures absolute parallelism between ram and table working surface.
Hydraulic presses operate by means of two or more synchronized hydraulic cylinders on the C-frames moving the upper or lower tooling by the means of a heavy-duty torque tube construction. These presses can move up or down at any point in their operation and can even be tilted by putting different loads on each cylinder, allowing for more complicated crowning control.
The versatile machine is known throughout the industry for exceptional value, and for years of dependable, low-maintenance service all over the world. Esskay lathe machines and tools have well known name Hydraullic press brake manufacturer, cnc lathe machine, miling machine etc.
Features:
- Simple & Flexible Controls
- Higher Accuracy
- More Versatility
- Greater Maintenance
- Easy Hydraulic System Maintenance
- Standard Components
- Flexibility
- Control
- Safety & Reliability
- Durability
PRODUCTS
| Modle No | Capacity(KN) | Bending(MM) | Distance Between Housings | Open Height | Close Height | Throat Depth | Table Height | Table Width | Approach | Bending | Return | Motor HP | Length | Width | Height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| EHPB - 2520 | 250 | 2000 | 1650 | 300 | 200 | 200 | 660 | 125 | 12 | 12 | 20 | 5 | 2100 | 750 | 2250 |
| EHPB - 4025 | 400 | 2500 | 2100 | 310 | 200 | 300 | 730 | 175 | 15 | 15 | 25 | 7.5 | 2600 | 1000 | 2325 |
| EHPB - 4030 | 400 | 3050 | 2560 | 310 | 200 | 300 | 730 | 175 | 15 | 15 | 25 | 7.5 | 3150 | 1000 | 2325 |
| EHPB - 8025 | 800 | 2500 | 2150 | 370 | 220 | 300 | 800 | 200 | 22 | 5 | 44 | 7.5 | 2600 | 1300 | 2675 |
| EHPB - 8030 | 800 | 3050 | 2600 | 370 | 220 | 300 | 800 | 200 | 22 | 5 | 44 | 7.5 | 3150 | 1300 | 2675 |
| EHPB - 8036 | 800 | 3600 | 3060 | 370 | 220 | 300 | 800+100 | 200 | 22 | 5 | 44 | 7.5 | 3700 | 1300 | 2675 |
| EHPB - 12525 | 1250 | 2500 | 2150 | 425 | 275 | 300 | 800+50 | 250 | 15 | 4 | 30 | 10 | 2600 | 1325 | 2850 |
| EHPB - 12530 | 1250 | 3050 | 2550 | 425 | 275 | 300 | 800+50 | 250 | 15 | 4 | 30 | 10 | 3150 | 1325 | 2850 |
| EHPB - 12536 | 1250 | 3600 | 3050 | 425 | 275 | 350 | 800+100 | 250 | 15 | 4 | 30 | 10 | 3700 | 1325 | 2850 |
| EHPB - 16025 | 1600 | 2500 | 2100 | 425 | 275 | 300 | 800+50 | 250 | 15 | 5 | 26 | 15 | 2600 | 1400 | 2850 |
| EHPB - 16030 | 1600 | 3050 | 2550 | 425 | 275 | 300 | 800+50 | 250 | 15 | 5 | 25 | 15 | 3150 | 1400 | 2850 |
| EHPB - 20025 | 2000 | 2500 | 2100 | 445 | 295 | 300 | 800+100 | 300 | 15 | 5 | 25 | 20 | 2600 | 1600 | 3000 |
| EHPB - 20032 | 2000 | 3200 | 2550 | 445 | 295 | 300 | 800+250 | 300 | 15 | 5 | 25 | 20 | 3300 | 1600 | 3000 |
| EHPB - 25032 | 2500 | 3250 | 2580 | 465 | 290 | 300 | 800+270 | 300 | 15 | 5 | 25 | 20 | 3250 | 1600 | 3000 |
| EHPB - 32032 | 3200 | 3250 | 2550 | 605 | 380 | 300 | 800+440 | 350 | 15 | 5 | 25 | 25 | 3350 | 1600 | 3650 |
| EHPB - 40032 | 4000 | 3250 | 2550 | 605 | 365 | 300 | 800+450 | 375 | 15 | 5 | 25 | 30 | 3350 | 1650 | 3050 |
| EHPB - 50042 | 5000 | 4200 | 3550 | 610 | 385 | 350 | 800+700 | 400 | 15 | 4 | 25 | 30 | 4300 | 1800 | 3750 |
